PA-15009P D6 Ball Magnetic Centering Probe | 6mm Reference Ball | EDM/CNC Workpiece Alignment
Enhanced Magnetic Reference Probe: 6mm Ball for Superior Workpiece Alignment
The PA-15009P D6 Ball Magnetic Centering Probe builds upon our magnetic centering series with an upgraded 6mm precision ball tip, providing improved visibility and contact surface for reference point establishment. This magnetic probe securely吸附 (adsorbs) to machine tables, offering a reliable datum point for precision workpiece positioning and centering operations in CNC and EDM applications.
Key Features & Benefits:
- •
⚡ 6mm Precision Ball Tip: Larger diameter provides enhanced visibility and improved contact surface for more accurate centering operations
- •
🧲 Magnetic Base Design: Offers secure adhesion to ferromagnetic machine tables without mechanical clamping, enabling quick placement and removal
- •
🎯 High Accuracy Reference: Serves as precise datum point for workpiece alignment, position verification, and machine calibration
- •
🛡️ Durable Construction: Stainless Steel 420 with 30-36 HRC hardness ensures longevity in demanding workshop environments
- •
🔧 Universal Compatibility: Compatible with all CNC and EDM machines featuring ferromagnetic work surfaces
Technical Specifications:
- •
Model: PA-15009P D6 Ball Magnetic Centering Probe
- •
Overall Dimensions: Φ38 × 100 mm
- •
Reference Ball: D6 (6mm) Precision Ball
- •
Material: Stainless Steel 420
- •
Hardness: 30-36 HRC
- •
Base Type: Magnetic Adhesion
- •
Application: Workpiece Centering & Machine Alignment
Operation Advantages:
- 1.
Place probe on clean machine table for instant magnetic adhesion
- 2.
Utilize 6mm ball as reference point for workpiece alignment
- 3.
Perform accurate centering operations using the visible ball tip
- 4.
Remove easily after operation completion
- 5.
Reuse multiple times without performance degradation
Applications:
- •
CNC machining center workpiece setup
- •
EDM electrode positioning and alignment
- •
Machine calibration and verification procedures
- •
Batch processing reference point establishment
- •
Precision manufacturing alignment operations
- •
Educational and training applications
Series Comparison:
Feature | PA-15008P (D4 Ball) | PA-15009P (D6 Ball) |
|---|---|---|
Ball Diameter | 4mm | 6mm (enhanced size) |
Visibility | Standard | Improved visibility |
Contact Surface | Standard | Larger contact area |
Alignment Precision | High | Enhanced accuracy |
