Multi-Angle EDM Innovation: Swivel Base Chuck for Complex Side Machining​

The ​PA-14003N Quick Chuck 50 with Swivel Base​ represents a breakthrough in EDM flexibility, building upon our PA-14001N design to enable unprecedented machining accessibility. This innovative system features a precision-engineered swivel base that allows 360° positioning, making it ideal for side machining, complex electrode operations, and unconventional machining angles that traditional fixed chucks cannot achieve.

​Key Advantages vs. Standard EROWA ER-034387:​​

• •

  ​🔄 360° Swivel Base:​​ Enables infinite angular positioning for side machining, undercut operations, and complex electrode approaches that require non-standard angles

• •

  ​🎯 Precision Angle Locking:​​ Micro-adjustment mechanism ensures accurate and repeatable positioning for critical EDM operations

• •

  ​🛡️ Complete Rust-Proof Construction:​​ 100% Nippon Stainless Steel construction (57-60 HRC) provides full corrosion resistance in demanding EDM environments

• •

  ​⚡ Quick-Change Compatibility:​​ Maintains identical 4000N clamping force and mounting pattern of the ER-034387 for seamless integration

• •

  ​🔧 Enhanced Machining Flexibility:​​ Solve complex mold manufacturing challenges with unconventional machining approaches and angles

​Technical Specifications:​​

• •

  ​Model:​​ PA-14003N Quick Chuck 50 with Swivel Base

• •

  ​Swivel Range:​​ 360° continuous rotation

• •

  ​Clamping Force:​​ 4,000 N

• •

  ​Material:​​ Nippon Stainless Steel

• •

  ​Hardness:​​ 57-60 HRC

• •

  ​Positioning Accuracy:​​ <0.01° angular precision

• •

  ​Mounting:​​ Standard ER-034387 compatible pattern

• •

  ​Included:​​ Stainless Steel Handle ×1 PC

​Specialized Applications:​​

• •

  Side machining and undercut EDM operations

• •

  Complex mold cavities requiring multi-angle approaches

• •

  Medical device components with intricate geometries

• •

  Aerospace parts with unconventional features

• •

  Multi-axis EDM machining with angular requirements

• •

  Prototype development requiring flexible positioning

​Comparison Advantage:​​
