PA-12005M Manual Chuck D100 with Vertical Base | Side Machining Solution | EROWA ER-036345 Compatibl
Vertical Machining Revolution: Side Operations Enabled with Innovative Base Design
The PA-12005M Manual Chuck D100 with Vertical Base introduces a groundbreaking approach to workpiece manipulation by orienting the chuck perpendicular to the machine table. This innovative design allows direct access to workpiece sides without complex fixturing or repositioning, significantly reducing setup time and expanding machining possibilities while maintaining full EROWA ER-036345 compatibility.
Key Features & Benefits:
- •
⬆️ Vertical Base Orientation: 90° mounted chuck enables direct side machining operations, eliminating need for additional fixtures or workpiece repositioning
- •
🔧 Full EROWA ER-036345 Compatibility: Maintains identical 10,000N clamping force and functional performance while offering revolutionary mounting orientation
- •
🛡️ Premium Nippon Stainless Steel: Complete unit constructed from corrosion-resistant stainless steel with 57-60 HRC hardness for maximum durability
- •
⚡ Immediate Side Machining Ready: Vertical orientation allows immediate access to workpiece sides for milling, drilling, and finishing operations
- •
🎯 Precision Performance: Guarantees <0.002mm repeat accuracy even in vertical orientation for critical side machining applications
Technical Specifications:
- •
Model: PA-12005M Manual Chuck D100 with Vertical Base
- •
Overall Dimensions: 130 × 100 × 81 mm (vertical orientation)
- •
Clamping Force: 10,000 N
- •
Material: Nippon Stainless Steel (complete unit)
- •
Hardness: 57-60 HRC
- •
Mounting Orientation: Vertical (90° to machine table)
- •
Included: Stainless Steel Handle ×1 PC
Specialized Applications:
- •
Side milling and drilling operations
- •
Complex workpiece side machining
- •
Multi-face processing without repositioning
- •
Mold and die side feature machining
- •
Prototype development with complex geometries
- •
Specialized fixture applications
Advantage Comparison:
Feature | Standard Horizontal Chuck | PA-12005M with Vertical Base |
|---|---|---|
Side Access | Requires repositioning | Direct side machining |
Setup Complexity | Multiple setups needed | Single setup solution |
Machining Flexibility | Limited plane access | Multi-plane capability |
Fixture Requirements | Additional fixtures needed | Self-contained solution |
