All Categories - plus auto solution
All
PLUS AUTO compatible system 3R
PLUS AUTO compatible Erowa
PA-17005R Self-Centering Vice for 5-Axis Machining | Compatible with EROWA ER-147223 & LANG Style
High-performance PA-17005R Self-Centering Vice designed for 5-axis heavy-duty cutting. Features a LANG-style vice body integrated with an EROWA ER-147223 G Plate for ITS 50 system compatibility. Center tolerance ±0.1mm. Made of Stainless Steel 420.
PA-17004R Angle Clamping Unit | Compatible with EROWA ER-028471 UnoSet
PA-17004R Angle Clamping Unit is a cost-effective alternative to EROWA ER-028471. Ideal for EDM/WEDM machining of lateral sprues on casting tools. Rotatable degree ±50° with 5° gap marks. Made of durable Stainless Steel 420.
PA-16004Q Adjustable Angle WEDM Holder | EROWA ER-017198 Replacement | 4000N Force |130×155×67mm
Advanced EROWA-compatible adjustable holder: The PA-16004Q Adjustable WEDM Holder (130×155×67mm) features angle-adjustable base with 4000N clamping force. Made from Nippon Stainless Steel (57-60 HRC), this precision fixture offers enhanced flexibility for wire-cut EDM applications at a competitive price point.
PA-16003Q Fixed Wire-Cut EDM Chuck | EROWA ER-022584 Replacement | 4000N Force |120×150×56mm
Premium EROWA ER-022584 alternative: The PA-16003Q Fixed Wire-Cut EDM Chuck (120×150×56mm) delivers 4000N clamping force with Nippon Stainless Steel construction (57-60 HRC). Includes stainless steel handle and offers direct compatibility with 100mm grid machine bases. Perfect for WEDM/EDM applications.
PA-17001R Square EDM Holder | Compatible with EROWA ER-093996 / ER-093997
High-precision PA-17001R Square EDM Holder, a premium alternative to EROWA ER-093996. Designed for ITS system size 50. Available in both 15mm and 25mm square slots. Made of corrosion-resistant Stainless Steel 420 (48-52HRC). C gripper slot customization available upon request for automated handling.
PA-17003R ER-32 Collet Chuck Holder | Compatible with EROWA ER-093999
High-precision PA-17003R ER-32 Collet Chuck Holder, a premium alternative to EROWA ER-093999. Designed for ITS System Size 50. Features exceptional ±0.015mm concentric tolerance after assembly. Made of Stainless Steel 420 (48-52HRC) with 1x Φ12 collet included.
PA-15010P D8 Ball Magnetic Centering Reference Probe | 8mm Precision Tip | EDM/CNC Alignment Tool
Premium magnetic reference probe: The PA-15010P D8 Ball Magnetic Centering Probe features an 8mm precision ball tip for superior visibility and accuracy in CNC/EDM workpiece alignment. With Φ38×100mm size and Stainless Steel 420 construction (30-36 HRC), this probe ensures reliable reference point establishment and rapid setup.
PA-15009P D6 Ball Magnetic Centering Probe | 6mm Reference Ball | EDM/CNC Workpiece Alignment
Enhanced magnetic centering solution: The PA-15009P D6 Ball Magnetic Centering Probe features a 6mm precision ball for superior reference point establishment on CNC/EDM tables. With Φ38×100mm size and Stainless Steel 420 construction (30-36 HRC), this probe ensures accurate workpiece alignment and rapid setup.
PA-16001Q V-Shape Wire-Cut EDM Holder | EROWA ER-016691 Replacement | ±0.005mm Concentric Tolerance
Precision wire-cut EDM solution: The PA-16001Q V-Shape EDM Holder (55×55×86.5mm) provides ±0.005mm concentric tolerance for EDM/WEDM applications. Made from Stainless Steel 420 (50-53 HRC), this V-block holder supports parts up to ø40×150mm with 1.5kg max load. Direct replacement for EROWA ER-016691.
PA-16002Q 3-Axis Precision Control Jig | EROWA ER-008856 Replacement | WEDM Fixturing Solution |
Premium EROWA alternative: The PA-16002Q 3-Axis High Precision Control Jig (60×55×97.2mm) offers multi-axis adjustable workpiece positioning for WEDM applications. Made from Stainless Steel 420 (50-53 HRC), this rotatable vise provides 360° continuous rotation and three-axis fine adjustment at a competitive price point.
PA-15002P D6 Centering Sensor | 6mm Tungsten Carbide Ball | EDM Touch Probe | ±0.002mm Accuracy
Precision EDM centering sensor with 6mm tungsten carbide ball: The PA-15002P D6 Centering Sensor provides accurate workpiece positioning with ±0.002mm concentric tolerance. Made from Stainless Steel 420 (32-36 HRC), this sensor offers reliable electrical contact detection for EDM spark machines and precision machining centers.
PA-15005P Gauging Pin | EROWA ER-008617 Replacement | ITS Chuck Alignment | ±0.002mm Concentric Tole
Precision ITS chuck alignment tool: The PA-15005P Gauging Pin (51×51×60mm) provides ±0.002mm concentric tolerance for radial, axial, and angular positioning of ITS chucks. Made from Stainless Steel 420 (48-52 HRC), this hardened and ground pin ensures perfect chuck centering during rotation.
PA-15004P Spring-Loaded Centering Sensor | EROWA ER-008638 Replacement | XYZ Overrun Protection
Premium EROWA alternative: The PA-15004P Spring-Loaded Centering Sensor features XYZ 1mm overrun protection and 0.002mm repetition accuracy. With spring-loaded sensing pin and tungsten carbide ball, this D4 sensor offers automatic workpiece measurement in CNC EDM centers at a fraction of EROWA's price.
PA-15003P D8 Centering Sensor | 8mm Tungsten Carbide Ball | EDM Touch Probe | ±0.002mm Accuracy
High-visibility EDM centering sensor: The PA-15003P D8 Centering Sensor features an 8mm tungsten carbide ball for superior durability and clear visibility during workpiece positioning. With ±0.002mm concentric tolerance and Stainless Steel 420 construction (32-36 HRC), it ensures precise electrical contact detection for EDM spark machines.
PA-15006P Parallel Gauging Pin | EDM/CNC Chuck Alignment Tool | ±0.002mm Flatness | EROWA-Compatible
Precision chuck alignment solution: The PA-15006P Parallel Gauging Pin (100×60×23mm) features ground flat top and side datum surfaces for quick chuck centering without rotation. Made from hardened Stainless Steel 420 (48-52 HRC) with ±0.002mm concentric tolerance. Perfect for EDM and CNC machine setup.
PA-16004Q Adjustable WEDM Holder | High Precision EDM Workholding
High-performance PA-16004Q adjustable WEDM holder made from premium Nippon Stainless Steel (57-60HRC). Features 4000N clamping force for stable and precise EDM/WEDM machining. Includes 1x stainless steel handle.
PA-15007P Extended Checking Pin | EROWA ER-010723 Replacement | Φ30×146mm | ITS Chuck Alignment | ±0
Extended-length alignment solution: The PA-15007P Checking Pin (Φ30×146mm) offers enhanced reach for ITS chuck positioning with ±0.005mm concentric tolerance. Made from Stainless Steel 420 (48-52 HRC), this hardened and ground pin provides precise radial, axial, and angular alignment at a fraction of EROWA's cost.
PA-15008P D4 Ball Magnetic Centering Probe | EDM/CNC Reference Point | Φ38×100mm
Magnetic reference solution: The PA-15008P D4 Ball Magnetic Centering Probe provides a reliable reference point for workpiece centering on CNC/EDM tables. With Φ38×100mm size and Stainless Steel 420 construction (30-36 HRC), this magnetic probe ensures quick setup and accurate positioning.
PA-18009S – Stainless Steel Replacement Ring for Movable Spigot Upper Part
Precision-machined replacement ring for the movable upper part of chucking spigots. Restores error compensation function after wear. Made from stainless steel for durability.
PA-17006R Magnetic Pallet for ITS 50 | Inspired by EROWA ER-137239 UPC
High-performance PA-17006R Magnetic Pallet adapted for EROWA ITS 50 system. Features an integrated ER-147223 centering plate, bringing UPC-level magnetic clamping functionality to standard ITS chucks. Ideal for EDM and CMM applications. Made of Stainless Steel 420.
Show more
